Features
- Measures overall vibration (velocity, displacement, acceleration) quickly for go/no-go checks.
- External sensor port + audio output jack for flexibility (e.g. external accelerometer, headphones).
- Compact and lightweight: easy to carry on site, quick setup.
- Long battery life (~25 hours of measurement) lets you cover lots of machines without frequent battery changes.
- Rugged environmental specs: works from ‒10 °C to +50 °C, high storage altitude, non-condensing humidity.
- Meets safety and EMC standards (IEC, CISPR) suitable for industrial settings.
Technical Specifications
| Specification | Details |
| Measurement Ranges | Velocity: 0.1 to 199.9 mm/s (RMS) Displacement: 0.001 to 1.999 mm (peak-peak) |
| Frequency Response | Typical: 10 Hz to 15 kHz |
| Amplitude Units | Acceleration: g, m/s²; Velocity: mm/s; |
| Vibration Limit | 500.0 m/s² peak |
| Battery / Power | 2 × AAA, IEC LR03, 3 V DC |
| Battery Life | 25 hours of measurement mode |
| Size (L × W × H) | 9.49 × 2.80 × 2.28 in (24.1 × 7.1 × 5.8 cm) |
| Weight | 0.485 lb (220 g) |
| Operating Temperature | 14 °F to 122 °F |
| Storage Temperature | ‒22 °F to 140 °F |
| Humidity | 30% to 90% RH non-condensing |
| Altitude | Operating ≤ 2000 m (~6,562 ft); Storage ≤ 12,000 m (~39,370 ft) |
