Features
- Triple-mode measurements: Acceleration, velocity, and displacement—all in one device.
- Durable and readable: Backlit LCD for dark environments, housed in sturdy ABS plastic.
- Performance-aware: ±5% accuracy is workable, but not lab-grade—good for field diagnostics, not precision labs.
- Battery efficiency: Runs on a common 9 V battery, not included. Auto-off feature saves power but always pack a spare.
- Hold function: Captures the peak reading. Handy for operators dealing with quick, hard-to-read spikes.
- User-friendly: Choose between Celsius or Fahrenheit for temperature readouts.
- Compact & Portable: Small footprint and light—easy to carry during inspections.
Technical Specifications
| Specification | Details |
| Measurement Modes | Acceleration, Velocity, Displacement |
| Sensing Technology | Piezoelectric ceramic accelerometer (shear-type) |
| Acceleration Range | 0.1 to 199.9 m/s² (peak) |
| Velocity Range | 0.1 to 199.9 mm/s (RMS) |
| Displacement Range | 0.001 to 1.999 mm (Peak-to-Peak) |
| Acceleration Frequency Range | 10 Hz to 1 kHz (Lo), 1 kHz to 15 kHz |
| Velocity Frequency Range | 10 Hz to 1 kHz |
| Displacement Frequency Range | 10 Hz to 1 kHz |
| Accuracy | ±5% full-scale ±2 digits |
| Display | 3½-digit LCD with backlight |
| Max Reading Hold | Yes |
| Temperature Display (°C/°F) | Selectable |
| Auto Power-Off | Yes |
| Power Supply | 9 V battery (not included) |
| Dimensions | 6.26 × 2.60 × 1.22 in (159 × 66 × 31 mm) |
| Weight | 5.47 oz (155 g) |
| Material | ABS plastic housing |
