Features
- Dual Functionality: Combines surface temperature measurement with real-time thermal imaging.
- High-Resolution Imaging: 160 x 120 resolution with 19,200 pixels for clear thermal visuals.
- 8 in Colour Display: Bright screen ensures visibility of thermal details and problem areas.
- Hot & Cold Spot Detection: Automatically marks highest and lowest temperature points.
- Adjustable Emissivity: 0.01 to 1.0 range improves accuracy on reflective surfaces.
- Selectable Colour Palettes: Choose from iron oxide, rainbow, or black-and-white modes.
- Storage & Reporting: Save thermal and visual images to a memory card (JPG format) for PC analysis and report generation.
- User-Friendly Controls: Language, unit adjustment, date/time setting, formatting, and auto shutdown options.
- Durability: IP54 waterproof rating and vibration resistance (2G, IEC 60068-2-6).
- Portable Power: Rechargeable 18650 battery for extended field use.
Technical Specifications
| Item | Specification |
| Type | Thermal Imager |
| Display | 2.8 in colour display |
| Resolution | 160 x 120 |
| Total Pixels | 19,200 |
| Field of View / Focus Length | 39° x 31° / 0.49 ft (0.15 m) |
| Thermal Sensitivity | 0.07 °C |
| Emissivity | 0.01 to 1.0 adjustable |
| Frame Rate | 30 Hz |
| Wavelength Coverage | 8 to 14 µm |
| Focus Mode | Fixed |
| Palette Options | Iron oxide, rainbow, black and white |
| Image Storage | Memory card (3 GB) |
| File Format | JPG |
| Controls | Unit adjustment, language, date/time, format, auto shutdown |
| Power Supply | Built-in rechargeable 18650 battery |
| Vibration Resistance | 2G, IEC 60068-2-6 |
| Waterproof Rating | IP54 |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Storage Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Humidity | <85% RH |
| Weight | 14.46 oz (410 g) |
| Size (L x W x H) | 8.90 in x 3.60 in x 2.82 in (226 x 91.5 x 71.6 mm) |
