Features
- Designed for hygiene: Stainless steel food-grade materials help prevent contamination and maintain compliance.
- Flexible screening options: By changing mesh layers or sieve size, you can tailor the sifter for coarse granules, fine powders or mixed materials.
- Adjustable capacity: Small units good for lab / pilot scale; large ones scale up to industrial throughput.
- Maintenance built-in: Cleaning systems (bouncing balls etc.), removable screens make cleaning much easier—important in food applications.
- Power vs performance trade-off: Large capacity and many layers require hefty motors and will draw more power; also, setup and frame strength become crucial.
- Heavy & bulky: Size and weight can make installation and shipping expensive; ensure your site can handle it.
Technical Specifications
| Specification | Details |
| Application | Food industry: grains, pellets, powders, chemicals (granule separation, impurity removal) |
| Material | Stainless Steel (304/316L) or Carbon Steel; food-grade finish |
| Mesh / Sieve Size / Screen Aperture | 1 mm to ~100 mesh (≈ 0.15–25 mm) depending on material & product purity needed |
| Number of Layers / Decks | 1 to 7 decks (layers) possible for multi-grade separation |
| Vibrating Motors | Usually 2 motors, sometimes adjustable frequency or amplitude; motor power depends on size & capacity |
| Power | Typical motor power from ~0.07 kW for small units up to several kWs for large capacity ones |
| Throughput / Capacity | Ranges from ~100-500 kg/h (smaller models) up to many tons/hour for large scale screens |
| Dimensions (L×W×H) | Depends on capacity & layers |
| Weight | Can be very heavy: hundreds of kg |
| Noise Level | ~ ≤ 75 dB for some food-grade models |
| Cleanability / Maintenance | Removable screens, bouncing balls or cleaning system, easy to disassemble for hygiene; cleaning system often included in design |
| Warranty / Support | Usually 1 year; spare parts & supplier support typical in good listings |
| Customization | Logo, mesh size, number of layers, voltage, finish, inlet/outlet orientation etc. |
