Features
- Pure sine wave AC output
- Maximum power point tracking
- App monitoring system
- Output voltage protection
- Adaptive voltage and frequency
- Over temperature protection
- Multiple parallel stacks
Technical Specifications
| Recommended Solar Panel Input Power (W) | 2 of 275 w to 400 W |
| Maximum DC Input Voltage | 52 V |
| Operating voltage range | 18 V to 48 V |
| Controller Type | MPPT |
| MPPT Tracking Range | 22 V to 48 V |
| MPPT Tracking Accuracy | Over 99.5 % |
| Maximum DC input current | 2 A of 12 A |
| Solar Panel Input Power | 600 W to 830 W |
| Rated Output Power | 800 W |
| Rated Output Voltage | 120 V or 230 V |
| Output Voltage Range | 90 V to 160 V or 190 to 270 V |
| Rated AC Current (at 120 V) | 6.6 A |
| Rated AC Current (at 230 V) | 3.47 A |
| Maximum Number of Branch Circuit Connections | 5 sets of 120 V AC and 10 sets of 230 VAC |
| Maximum Conversion Efficiency | 95 % |
| Rated Output Frequency | 50 Hz or 60 Hz |
| Protection class | IP 65 |
| Working environment temperature | – 40 F to 149 °F (- 40 ℃ to 65 ℃) |
| Communication Connection Mode | WIFI or 2.4 G |
| Indicator Lights Quantity | 1 Working status LED light and 1 WIFI signal led light |
| Cooling Method | Natural cooling (no fan) |
| Working Environment | Indoor and outdoor |
| Size | 13.34 in x 9.45 in x 3.74 in (34 cm x 24 cm x 9.5 cm) |
| Weight | 5.51 lb. (2500 kg) |
