Technical Specifications
| Communication Mode | LoRaWAN, M-Bus, RS485, Pulse, GPRS, NB-IoT |
| Nominal Diameter | DN50 – DN250 (2 in to 10 in) |
| Material | Cast iron, stainless steel |
| Maximum Working Pressure | 1.6 MPa (232 psi) |
| Minimum Flow Rate | 0.020 m³/h (0.53 gal/h) |
| Accuracy | Class B, ±2% |
| Pressure Loss | Δp 40 (0.58 psi) |
| Protection Class | IP68 |
| Temperature Range | -22 °F to 131 °F (-30 °C to 55 °C) |
| Service Life | ≥6 years |
| Data Storage | 48 months |
| Power Supply | Lithium Battery, 24V DC |
| Installation | Horizontal or Vertical |
| Flow Rate Range | Q3/Q1 = 250, Q2/Q1 = 1.6, Q4/Q3 = 1.25 |
| Range Ratio | Q3/Q1 = 250, Q2/Q1 = 1.6, Q4/Q3 = 1.25 |
| Weight | 15.43 lb (7 kg) |
