Features
- It captures both waveform & FFT spectrum for two channels—good for comparing two sensors or two measurement points at once.
- Spectrum span choices up to 10 kHz let you examine mid- to high-frequency vibrations (bearings, gears etc.).
- 100-400 line resolution with Hanning windowing gives decent clarity—not ultra high resolution like lab-grade, but solid for field diagnostics.
- Storage of 1024-point data means you can record rich snapshots, do post-processing later.
- USB transfer means you’re not stuck manually reading; you can move data to PC for deeper analysis.
- Used for dynamical balancing, fault diagnosis, site vibration measurement.
Technical Specifications
| Specification | Details |
| Number of Channels | 2 simultaneous vibration channels |
| Measurements / Analysis Modes | FFT spectrum display, waveform display, transfer function analysis |
| Frequency Span (“spectrum span”) | 100 Hz, 200 Hz, 500 Hz, 1 kHz, 2 kHz, 5 kHz, 10 kHz |
| Lines of Spectrum (Resolution) | 100 to 400 lines, using Hanning window |
| Sampling / Data Points | 1024-point time records (per channel) |
| Data Storage | Stores waveform + spectrum data |
| Display | On-device display of waveform + spectrum |
| Output / Interface | USB interface for data transfer |
| Application / Use Case | Machinery diagnostics, dynamic balancing, site vibration monitoring |
