Technical Specifications
| Chipset | QCA9531 + QCA9887 |
| Antenna Type | IPEX |
| Network | 1WAN or 4LAN , 10 or 100Mbps |
| Wireless Standards | IEEE 802.11 a or b or g or n or ac |
| Voltage | 3.3V±5% |
| Ethernet | 1 x SPI, 1 x UART, 1 x USB2.0, 10 x GPIO |
| Wireless Security | WPA or WPA2, WEP, TKIP and AES, WPS2.0, WAPI |
| Work Mode | Bridge or Gateway or AP Client |
| Wireless Standards | IEEE 802.11 a b g n Ac |
| Frequency Range | 2412GHz—2484MHz |
| Data Rates | IEEE 802.11n : MCS0–MCS7 @ HT20 IEEE 802.11n : MCS0–MCS7 @ HT40 IEEE 802.11g : 6,9,12,18,24,36,48,54Mbps IEEE 802.11b : 1,2,5.5,11Mbps IEEE 802.11ac : MCS0–MCS9 @ VHT80 5GHz Band |
| Receiver Sensitivity | VHT80 MCS9 : -58dBm@10% PER(MCS9) 5GHz band HT40 MCS7 : -69dBm@10% PER(MCS7)HT20 MCS7 : -71dBm@10% PER(MCS7) 54M: -75dBm@10% PER 11M: -88dBm@ 8% PER |
| Modulation Technique | DSSS (DBPSK, DQPSK, CCK) OFDM (BPSK, QPSK, 16-QAM, 64-QAM, 125-QAM, 256-QAM) |
| Wireless Security | WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI |
| Transmit Power | IEEE 802.11ac: 12±2dBm @HT80 MCS9 5GHz band IEEE 802.11ac: 16±2dBm @HT80 MCS0 5GHz band IEEE 802.11n: 13-16dBm @HT20/40 MCS7 IEEE 802.11g: 14-17dBm @54MHz IEEE 802.11b: 16-20dBm @11MHz |
| Work Mode | Bridge or Gateway or AP Client |
| Dimension | 1.97 inches × 1.18 Inches × 0.35 Inches (50 mm x 30 mm x 9.0 mm) |
