Technical Specifications
| Input Voltage | 90 VACS to 280VAC ± 3 V (Normal Mode)
185 VACS to 264 VAC ± 3 V (UPS Mode) |
| Output Voltage | 220 VACS
230 VACS 240 VACS ± 5% |
| Output Current | Dependent on connected load and conditions |
| Output Frequency | 50 Hz or 60 Hz (Adaptive) |
| Maximum PV Array Power | 7500 W |
| Maximum PV Voltage | 500 V DC |
| PV voltage range | 60 V DC to 500 V DC |
| Controller type | MPPT Solar Controller |
| Maximum solar charging current | 100 A |
| Maximum AC Charge Current | 80 A |
| Size | 19 in x 12 in x 5.5 in (49 cm x 31 cm x 14 cm) |
| Weight | 22 lbs. (10 kg) |
