Features
- Measures pressure from -14 to 870 psi (-1 to 60 bar) with ±0.5% FS accuracy
- Temperature range of -58 °F to 302 °F (-50 °C to 150 °C) with ±0.9 °F accuracy
- Built-in Bluetooth connectivity for real-time data transfer and mobile monitoring
- Includes wired clamp-on temperature probe for direct measurement
- IP67-rated, compact, and rugged design for water/dust resistance and field portability
- Compatible with multiple refrigerants for versatile HVAC testing
Technical Specifications
| Product Type | Digital Refrigerant Meter |
| Pressure Measuring Range | -14 to 870 psi (-1 to 60 bar) |
| Pressure Accuracy (at 71.6 °F) | ±0.5% FS |
| Temperature Measuring Range | -58 to 302 °F (-50 to 150 °C) |
| Temperature Accuracy | ±0.9 °F |
| Protection Class | IP67 (water and dust resistant) |
| Power Supply | 4 × AA batteries |
| Auto Power Off | After 10 minutes (no Bluetooth connection) |
| Connectivity | Bluetooth wireless communication |
| Probe Type | Wired clamp-on temperature probe |
| Display | Digital LCD display |
| Operating Voltage | 220 V |
| Operating Temperature Range | 32 °F to 104 °F (0 °C to 40 °C) |
| Dimensions | 19.69 in x 11.81 in x 13.78 in (50 cm x 30 cm x 35 cm) |
| Weight | 11.02 lb (5 kg) |
