Overview
Hospitality Enviro Tech Digital Clamp Phase Meter is an electronic instrument used to measure the phase difference between two alternating current (AC) signals. It is a specialized version of a digital clamp meter that includes phase measurement capabilities. The device is particularly useful in electrical and electronics applications where phase synchronization and analysis are essential.
Features
- Rugged design
- Interchangeable connector adapters
- 300 hours of battery life
- Tone recognition for ½ ber ½ cation
- Universal push-pull interface
- Reference function for direct loss measurements
Technical Specifications
| Detector Type | InGaAs |
| Central wavelength (nm) | 1310 ± 20 1550 ± 20 |
| Spectral width (nm) | ≤ 5 |
| Output power (dBm) | ≥ –5 |
| Power stability (dB) | ± 0.10 |
| Battery life (hours) | 60 |
| Tone generation (Hz) | x 270, 1 k, 2 k |
| Resolution (dB) | 0.01 dB |
| Operation environment (Temperature) | 14 °F to 122 °F ( -10 °C to 50 °C ) |
| Storage Temperature | – 40 °F to 158 °F ( – 40 °C to 70 °C ) |
| Operating humidity | 0 to 95 %RH |
| Size | 7.44 in x 3.07 in x 1.45 in (189 mm x 78 mm x 37 mm) |
| Weight | 0.9 lb. (400 g) |
