Features
- True RMS measurement for precise AC readings
- Compact and ergonomic design for easy one-hand operation
- Large digital backlit display for clear data visibility
- Autoranging for simplified measurement setup
- Data Hold, Max/Min, and REL (Zero) functions for accuracy and flexibility
- Non-contact voltage (NCV) detection for enhanced safety
- Low battery indication and auto power-off for extended battery life
- 57 in (40 mm) jaw opening for measuring larger conductors
- Rugged double-molded plastic housing for durability
Technical Specifications
| AC Current | 1000 A and Accuracy: ±(2.5% + 8d) |
| DC Current | 1000 A and Accuracy: ±(2.0% + 5d) |
| AC Voltage | 600 V and Accuracy: ±(1.0% + 5d) |
| DC Voltage | 600 V and Accuracy: ±(0.8% + 2d) |
| Resistance | 60 MΩ and Accuracy: ±(1.0% + 3d) |
| Capacitance | 4000 µF and Accuracy: ±(3.0% + 5d) |
| Frequency | 10 Hz to 10 kHz and Accuracy: ±(0.5% + 2d) |
| Duty Cycle | 1% to 99% and Accuracy: ±(0.5% + 3d) |
| Temperature | 32 °F to 140 °F (0 °C to 60 °C) and Accuracy: ±(1.0% + 3d) |
| Display Count | 2000 Counts |
| Display Type | Digital Backlit LCD |
| Safety Rating | CAT III 600 V |
| Jaw Opening | 1.57 in (40 mm) |
| Continuity Check | Audible buzzer at 50 Ω |
| Diode Test | Test current 0.3 mA |
| Power Supply | 9 V Battery |
| Operating Temperature | 32 °F to 113 °F (0 °C to 45 °C) |
| Dimensions | 9.05 in × 2.99 in × 1.57 in (230 mm × 76 mm × 40 mm) |
| Weight | 0.69 lb (315 g) |
