Features
- Measures AC/DC current up to 1000 A with high accuracy
- AC/DC voltage measurement up to 600 V with auto-ranging function
- Wide frequency range from 40 Hz to 400 Hz for versatile applications
- Large digital display with clear readings and stable measurement
- Withstand voltage of 6880 V AC for 5 seconds ensures safety in operation
- Complies with IEC61010-1 CAT IV 600V, IEC61010-2-032, and IEC61326 safety standards
- Compact and lightweight handheld design for portable use
- Powered by 2 x AAA 1.5 V batteries for convenience
- Durable build for use in electrical maintenance, industrial, and field testing
- Reliable Japanese engineering with fast response and stable operation
Technical Specifications
| Product Type | AC or DC Digital Clamp Meter |
| AC Current Range | 0 to 600 A or 1000 A ±1.5%rdg ±5dgt at 50 or 60 Hz; ±3.0%rdg ±5dgt at 40 to 400 Hz |
| DC Current Range | 0 to 600 A or 1000 A ±1.5%rdg ±5dgt |
| AC Voltage Range | 6 V or 60 V or 600 V (Auto Ranging); ±1.3%rdg ±4dgt at 50 or 60 Hz; ±3.0%rdg ±5dgt at 40 to 400 Hz |
| DC Voltage Range | 600 mV or 6 V or 60 V or 600 V (Auto Ranging); ±1.0%rdg ±3dgt |
| Frequency Range | 40 Hz to 400 Hz |
| Withstand Voltage | 6880 V AC for 5 seconds |
| Safety Standards | IEC61010-1 CAT IV 600V, IEC61010-1-031, IEC61010-2-032, IEC61326 |
| Power Supply | 2 × AAA 1.5 V batteries |
| Dimensions (Unit) | 10.0 in x 3.2 in x 1.4 in (254 mm x 82 mm x 36 mm) |
| Weight (Unit) | 10.93 oz (310 g) |
| Dimensions | 13.39 x 9.84 x 7.48 in (34 cm x 25 cm x 19 cm) |
| Weight | 3.31 lb (1.5 kg) |
