Features
- Supports multiple serial, automotive, and audio protocols
- Ideal for power loss, ripple, and noise measurement analysis
- Detects rare glitches, timing issues, and amplitude variations
- Enables detailed debugging of embedded and wireless systems
- Advanced digital fluorescence display for clear signal visualization
Technical Specifications
| Oscilloscope Type | Digital Storage |
| Bandwidth Options | 50MHz, 70MHz, 100MHz, 200MHz |
| Oscilloscope Channels | 2 Or 4 |
| Maximum Sampling Rate | 1GSa/s |
| Memory Depth per Channel | 10Mpts |
| Waveform Update Rate | 50,000 wfms/s |
| Display Size | 7 Inch WVGA |
| Display Resolution | 800 × 480 |
| Display Features | 256 Color Gradient Waveform Display |
| FFT Display Points | 1Mpts |
| Serial Bus Trigger and Decoding | I2C, SPI, UART, CAN, LIN |
| Special Function | Zero Key For Time, Voltage, And Triggering |
| Operating Temperature | 32 °F To 104 °F (0 °C To 40 °C) |
| Product Weight | 5.5 lb (2.5 kg)Estimated For Benchtop Unit |
| Dimensions | 12.6 in x 6.3 in x 5.1 in (32 cm x 16 cm x 13 cm) |
