Features
- Single-phase relay-based voltage stabilizer
- High efficiency with reliable performance
- LED display for clear voltage monitoring
- Multiple protections: overload, short circuit, over/under voltage, and over temperature
- Durable aluminum construction
- Compact design with toroidal transformer for stability
- Suitable for gas boilers, refrigerators, and air conditioners
Technical Specifications
| Specification | Details |
| Capacity | 500 VA, 1000 VA, 1500 VA, 2000 VA, 3000 VA, 5000 VA, 8000 VA, 10 000 VA |
| Current Type | AC |
| Phase | Single Phase |
| Type | Relay Voltage Stabilizer |
| Efficiency | 0.9 |
| Frequency | 50 Hz to 60 Hz |
| Material | Aluminium |
| Protection | Short Circuit, Overvoltage, Over Temperature, Overloading, Undervoltage |
| Usage | Voltage Regulator |
| Output Voltage | 220 V ±10% |
| Input Voltage | 105 V to 270 V |
| Color | White or Black |
| Display | LED Display |
| Application | Gas Boiler, Air Conditioner, Fridge, etc. |
| Control Type | 5 Relays |
| Transformer | Toroidal Transformer |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Weight | 11 lb (5 kg) |
| Dimensions (L x W x H) | 12.0 in x 8.0 in x 6.0 in (305 mm x 203 mm x 152 mm) |
