Technical Specifications
| Type | 2.4GHz & 5GHz Antenna |
| Frequency Range (MHz) | 2400 MHz to 2500MHz |
| Gain (dBi) | 12dbi |
| F/B (dB): | ≥11 |
| VSWR: | ≤2 |
| Input Impedance (Ω): | 50 |
| Maximum Power (W) | 100 |
| Lightning Protection: | DC grounding |
| Connector | SMA J or customizable |
| Materal | ABS |
| Color | white |
| Horizontal Beamwidth | 65° |
| Vertical Beamwidth | 55° |
| Nominal Impedance | 50Ω |
| Maximum Power | 100W |
| Connector | SMA-male or can be customized |
| Mounting Type | Wall Mount |
| Operating Temperature | -40°F to 167°F (-40 ℃ to +75℃) |
| Dimensions | 5.63 inches x 4.76 inches x 1.65 inches
(143 mm x 121 mm x 42 mm) |
