Features
- True-RMS: Accurate measurements, even with non-sinusoidal signals
- Capacitance: Verify motor capacitors
- Resistance and continuity: Check connections and coils
- 3-phase Motor and Phase Rotation: Prevent motor damage
- Low Pass filter: Precise readings on VFDs
- DC Microamps output: Test gas appliance flame sensor safety systems
- Monitor motor start-up for proper current support
- Measures temperature from -40 °F to 752 °F (-40 °C to 400 °C)
- Measures DC Microamps for flame sensor testing on gas appliances
- Measures capacitance, test diodes, and features a continuity beeper
- Tests 3-phase sequence and motor rotation to ensure proper
- connection of a motor to a 3-phase system
- Monitors inrush current during motor start-up
- True-RMS sensing for accurate voltage in noisy environments
- Amp-Tip function for precise low AC current measurements (0 to 60 A)
Technical Specifications
| Measuring Voltage Range | 1000 V |
| Measuring Current Range | 0 A to 1000 A |
| Operating Temperature | -40 °F to 752 °F (-40 °C to 400 °C) |
| Maximum AC or DC voltage | 1000 V |
| Maximum AC or DC current | 1000 A |
| True RMS | Yes |
| Dimensions | 13.75 in x 3.70 in x 1.73 in (369.25 mm x 93.98 mm x 43.94 mm) |
| Weight | 0.93 lb (421.1 g) |
