| Parameter |
Specification |
| PM1 |
Laser sensor, 0–200 µg/m³, 1 µg/m³ resolution |
| PM2.5 |
Laser sensor, 0–500 µg/m³, 1 µg/m³ resolution |
| PM10 |
Laser sensor, 0–1000 µg/m³, 1 µg/m³ resolution |
| O₃ (Ozone) |
Electrochemical sensor, 0–1800 ppb or µg/m³, 1 ppb/1 µg/m³ resolution |
| CO (Carbon Monoxide) |
Electrochemical sensor, 0–6000 ppb or µg/m³, 1 ppb/1 µg/m³ resolution |
| SO₂ (Sulfur Dioxide) |
Electrochemical sensor, 0–10,000 ppb or µg/m³, 1 ppb/1 µg/m³ resolution |
| NO₂ (Nitrogen Dioxide) |
Electrochemical sensor, 0–4000 ppb or µg/m³, 1 ppb/1 µg/m³ resolution |
| NO (Nitric Oxide) |
Electrochemical sensor, 0–4000 ppb, 1 ppb resolution |
| CO₂ (Carbon Dioxide) |
IR sensor, 0–5000 ppm or mg/m³, 1 ppm/1 mg/m³ resolution |
| Temperature |
-40℃ to 100℃, 0.1℃ resolution |
| Humidity |
0–100% RH, 0.1% RH resolution |
| Barometric Pressure |
800–1100 KPa |
| Noise |
35–100 dB |
| Preheat Time |
30 seconds |
| Protection Level |
IP66 |
| Product Size (L×W×H) |
400 × 230 × 600 mm |
| Weight |
25 kg |
| Power Supply |
220V, 50Hz; Input Voltage: 24VDC |
| Working Environment |
-40℃ to +70℃, ≤95% RH (non-condensing), 0.1 MPa ±20% |
| Warranty |
1 year |
