Features
- ISO,CE,FCC, ROHS, ATEX,CNEX,SIL3 Approved
- Upto 6 gases simultaneously detection
- Android OS, support remote maintenance and OTA remote wireless upgrade
- GPS/ precise positioning, LED lighting, SOS one-key call for help, 3D intelligent fall alarm, one-key positioning upload
- Built-in pump with 1000ml/m flow rate, 0.2m swan sampling probe
- Alarm types: LOW, HIGH, TWA ,STEL, alarm, concentration alarm, under pressure alarm, fault alarm, pump blockage alarm, man fell down alarm
- Alarm mode: sound and light alarm, sound and light + visual alarm, vibration alarm, voice (multi-language) alarm
- Communication: Type C, WiFi and Bluetooth
- Optional: Bluetooth printer, 4G, Display user information, real-time location, concentration information, longitude and latitude, custom address information, track query on the map,One-click photo taking (＞ 800W pixels)
- PC software for data acquisition and analysis
- 4 inch High-definition color screen, touchable screen, 800*480 pixels
- Zero point automatic tracking
- Automatic calibration with calibration system or manual calibration
- 16G big storage, 10,000,000 logs
- Anti-drop height: ≥ 2 meters
- High-strength, corrosion-resistant, fire-resistant polycarbonate and rubber protective housing,anti-fall, wear-resistant and anti-static
Technical Specifications
| Detection Method | Pumped |
| Battery | 10000mAh rechargeable lithium battery |
| Protection Level | IP66 |
| Product Size | 210×93×70mm (L×W×H) |
| Weight | About 700g |
| Protection Grade | Exia II CT4 Ga |
| Working Environment | -20℃～+50℃, ≤95%RH (non-condensing occasions) |
Additional Specifications
| Parameter | Sensor Type | Range | Resolution | Accuracy | Response Time |
| CO | Electrochemical sensor | 0-100ppm | 0.01ppm | ≤±2% (F.S) | T90≤20S |
| CO2 | IR sensor | 0-5000ppm | 1ppm | ≤±2% (F.S) | T90≤20S |
| NOx | Electrochemical sensor | 0-1ppm | 0.001ppm | ≤±2% (F.S) | T90≤20S |
| SO2 | Electrochemical sensor | 0-1ppm | 0.001ppm | ≤±2% (F.S) | T90≤20S |
| HCHO | Electrochemical sensor | 0-1ppm | 0.001ppm | ≤±2% (F.S) | T90≤20S |
| O2 | Electrochemical sensor | 0-30%VOL | 0.01%VOL | ≤±2% (F.S) | T90≤20S |
| PM2.5 | Laser sensor | 0-1000ug/m3 | 1ug/m3 | ≤±2% (F.S) | T90≤20S |
| PM10 | Laser sensor | 0-1000ug/m3 | 1ug/m3 | ≤±2% (F.S) | T90≤20S |
