Features
- Pure sine wave solar inverter (on or off Grid
- Inverter running without battery
- Output power factor 1.0
- High PV input voltage range (90 to 500 VDC)
- WIFI and GPRS can be used with IOS and Android
- Built-in anti-dusk kit for harsh environment
- Built-in 160 A (for 7.2 KW or 8.2 KW or 180A（for 10.2 KW）MPPT solar charge
- Smart battery charge design to optimize battery life
- One-click restoration to factory Settings
- Dual output
- Built-in Lithium battery automatic activation
- Touch bottom
Technical Specifications
| Phase | 1 – phase |
| Maximum PV Input Power | 10200 W |
| Rated Output Power | 10200 W or 10200 VA |
| Maximum Solar Charging Current | 180A |
| Nominal DC Voltage and
Maximum DC Voltage |
360 VDC or 500 VDC |
| Start-up Voltage and
Initial Feeding Voltage |
90 VDC or 120 VDC |
| MPPT Voltage Range | 90 VDC to 450 VDC |
| Number Of MPPT Trackers
Maximum Input Current |
1
27 A |
| Nominal Output Voltage | 200 or 230 or 240 VAC |
| Output Voltage Range | 195.5 to 253 VAC |
| Nominal Output Current | 44.3 A |
| Power Factor | Over 0.99 |
| Maximum Conversion Efficiency (DC or AC) | 98 % |
| Full Load | 10200 W |
| Maximum Main Load | 10200 W |
| Main Load Return Voltage | 3400 W |
| Main Load Cut Off Voltage | 44 VDC |
| Main Load Return Voltage | 48 VDC |
| AC Start-up Voltage
Auto Restart Voltage |
120 to 140 VAC
180 VAC |
| Acceptable Input Voltage Range | 90 to 280 VAC or 170 to 280 VAC |
| Maximum AC Input Current | 50 A |
| Nominal Operating Frequency | 50 or 60 Hz |
| Surge Power | 20400 W |
| Maximum DC Voltage | 500 VDC |
| MPPT Voltage Range | 90 VDC to 450 VDC |
| Number of MPPT Trackers and
Maximum Input Current |
1
27 A |
| Nominal Output Voltage | 48 VDC |
| Output Waveform | Pure sine wave |
| Efficiency (DC to AC) | 94 % |
| Maximum Solar Charging Current | 180 A |
| Maximum AC Charging Current | 160 A |
| Size | 21.14 in x 15.35 in x 5.12 in (53.7 cm x39 cm x 13 cm) |
| Weight | 31.31 lb (14.2 kg) |
