Features:
- Protocol IEEE 802.11ah 902 to 928MHz IEEE 802.11b/g/n（2412-2472MHz)
- Communication bandwidth8MHz
- data rate maximum 16Mbps
- Receiver sensitivity 1M PPDU MCS=10 –105dbm 8M PPDU MCS=0 –95dbm 8M PPDU MCS=7 –81dbm
- Number of supported network nodes Up to 8 access points
- Transmit power 20dBm 100mW
- Debugging methodBPSK，QPSK，QAM16 or QAM64
- Transmission distance the maximum distance is 1000 meters, and the non
- Communication distance is 300 meters
- Safety regulations WPA2-PSK
Technical Specifications
|
Protocol |
IEEE 802.11ah (902 to 928MHz) IEEE 802.11 b or g or n (2412-2472MHz) |
| Communication Bandwidth | 8MHz |
| Data Rate | Maximum 16Mbps |
| Receiving Sensitivity | 1M PPDU MCS=10 -105dbm
8M PPDU MCS=0 -95dbm 8M PPDU MCS=7 -81dbm |
| Number of Supported Network Nodes | Up to 8 Access Points |
| Transmit power | 20dBm 100mW |
| Commissioning mode | BPSK, QPSK, QAM16 or QAM64 |
| Transmission Distance | Maximum 1000 meters for intervisibility,
300 meters for non-intervisibility |
| Security specification |
WPA2 PSK |
| Encryption | AES |
| Hardware | 10 or 100Mbps |
| Power Supply | Type C 5V or 1A |
|
LED Indication |
Power Indicator
Connection Indicator Link Building Indicator |
| Antenna Interface | Built-in Antenna |
| Input Voltage | 5V1A |
| Maximum Current | 500mA |
| Average Power Consumption | 1.5 Watt |
| Operating Temperature | 4 °F to 158 °F (-20 °C to 70 °C) |
| Storage Temperature | -22 °F to 176 °F (-30 °C to 80 °C) |
| Operating Humidity | 10% to 90% |
| Storage Humidity | 5% to 95% |
| Product Size | 2.09 in x 0.73 in (53 mm x 18.6 mm) |
| Product Weight | 4.23 oz (120g) |
