Overview
The circuit is connected from a strong current box, and even a decorated house only needs small modifications without damaging the original decoration. More home appliances can be connected to easily meet electricity needs. Daily household equipment can be connected to refrigerators, air conditioners, televisions, lighting, and conventional appliances.
Features
- Pure sine wave
- Constant stable voltage
- Adaptability
- Large screen display
Technical Specifications
| Rated Power | 4000 VA or 4000 W |
| Voltage | 230 VAC |
| Selectable Voltage Rang | 170 VAC to 280 V AC (For Personal Computers
90 VAC to 280 V AC (For Home Appliances） |
| Frequency Range | 50 Hz or 60 Hz (Auto sensing） |
| Surge power | 8000 VA |
| AC Voltage Regulation (Battery Mode） | 230 VAC plus or minus 5 % |
| Rated frequency | 50 Hz or 60 Hz |
| Efficiency (Peak） | up to 93.5 % |
| Transfer Time | 10 minutes (For Personal Computers
20 minutes (For Home Appliances） |
| Battery voltage | 24 V DC |
| Floating Charge voltage | 27 V DC |
| Overcharge Protection | 33 V DC |
| Battery type | Lithium or Lead acid |
| Maximum PV Array Open Circuit Voltage | 500 V DC |
| Maximum PV Array Power | 5000 W |
| MPPT voltage range(V) | 60 VDC to 450 V DC |
| Maximum input current | 27 A |
| MPPT tracker/strings | 1 |
| Maximum Solar Charge Current | 120 A |
| Maximum AC Charge Current | 100 A |
| Maximum Charge Current | 120 A |
| Operating Temperature | – 32 °F to 131 °F (0 °C to 50 °C) |
| Relative humidity | 0 % to 95 % (non-condensing) |
| Altitude | Over 1.24 Mi (2,000 M) Derating |
| Display | Touch screen |
| Communication Interface | Standard RS 232 or CAN and RS 485 or Optional WIFI or Bluetooth |
| Safety standard | EN or IEC 62109 – 1 and EN or IEC 62109 – 2 |
| Dimensions D x W x H | 13.7 in x 10.63 in x 3.74 in (34.8 cm x 27 cm x 9.5 cm) |
| Net Weight | 11.02 lbs. (5000 g) |
